FIBARO

Wall Roller Shutter

SKU: FGWREU-111

ZWave+ Security V2

Quickstart

This is a secure Window Covering - Endpoint Aware for CEPT (Europe). To run this device please connect it to your mains power supply. To add this device to your network execute the following action:
To add the device to the Z-Wave network manually:1.Power the device.2.Set the main controller in (Security/non-Security Mode) add mode (see the controllers manual).3.Quickly, three times click one of the buttons.4.If you are adding in Security S2 Authenticated, scan the DSK QR code or input the underlined part of the DSK (label on the bottom of the box).5.LED will start blinking yellow, wait for the adding process to end.6.Adding result will be confirmed by the Z-Wave controllers message and the LED frame:- Green - successful (non-secure, S0, S2 non-authenticated),- Magenta - successful (Security S2 Authenticated),- Rednot successful.To add the device to the Z-Wave network using SmartStart:1.Set the main controller in Security S2 Authenticated add mode (see the controllers manual). 2.Scan the DSK QR code or input the underlined part of the DSK (label on the bottom of the box).3.Power the device.4.Wait for the adding process to start (up to few minutes), which is signaled with yellow LED blinking.5.Adding result will be confirmed by the Z-Wave controllers message and the LED frame:- Green - successful (non-secure, S0, S2 non-authenticated),- Magenta - successful (Security S2 Authenticated),- Rednot successful.

Attention: This manual is automatically generated from Z-Wave Alliance Product data and may be incomplete. Please refer to the Manufacturers Manual for more information.


Important safety information

Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.

What is Z-Wave?

Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.

Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is not in direct wireless range of the transmitter.

This device and every other certified Z-Wave device can be used together with any other certified Z-Wave device regardless of brand and origin as long as both are suited for the same frequency range.

If a device supports secure communication it will communicate with other devices secure as long as this device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level of security to maintain backward compatibility.

For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.

Product Description

FIBARO Walli Roller Shutter is a smart wall switch designed to control motors of roller blinds, awnings, venetian blinds and other single phase, AC powered devices via Z-Wave network. It measures active power andenergy consumed by the controlledload. You can install it with provided cover plate or other compatible.Main features of FIBARO Walli Roller Shutter:- Can be used with:oRoller blinds,oVenetian blinds,oAwnings,oBlind motors with electronic or mechanical limit switches.- Can be used with provided cover plate or one of the following:oGIRASystem 55 (Standard 55, E2, Event, Event Clear),oLegrandCliane,oSchneiderOdace.- Active power and energy consumption metering.- Supports Z-Wave network Security Modes: S0 with AES-128 encryption and S2 Authenticated with PRNG-based encryption.- Works as Z-Wave signal repeater (all non-battery operated devices within the network will act as repeaters to increase reliability of the network).- May be used with all devices certified with the Z-Wave Plus certificate and should be compatible with such devices produced by other manufacturers.

Prepare for Installation / Reset

Please read the user manual before installing the product.

In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended to use the primary controller of the previous network to make sure the very device is excluded properly from this network.

Reset to factory default

This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.

Reset procedure allows to restore the device back to its factory settings, which means all information about the Z-Wave controller and user configuration will be deleted. Resetting to factory defaults does not reset energy consumption memory.1.Quickly, three times click, then press and hold one of the buttons to enter the menu.2.Release the button when the device glows yellow.3.Quickly click the button to confirm.4.After a few seconds the device will be restarted, which is signalled with the red LED colour.

Safety Warning for Mains Powered Devices

ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to the assembly of the product, the voltage network has to be switched off and ensured against re-switching.

Inclusion/Exclusion

On factory default the device does not belong to any Z-Wave network. The device needs to be added to an existing wireless network to communicate with the devices of this network. This process is called Inclusion.

Devices can also be removed from a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network. This controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is then performed doing a special manual action right on the device.

Inclusion

To add the device to the Z-Wave network manually:1.Power the device.2.Set the main controller in (Security/non-Security Mode) add mode (see the controllers manual).3.Quickly, three times click one of the buttons.4.If you are adding in Security S2 Authenticated, scan the DSK QR code or input the underlined part of the DSK (label on the bottom of the box).5.LED will start blinking yellow, wait for the adding process to end.6.Adding result will be confirmed by the Z-Wave controllers message and the LED frame:- Green - successful (non-secure, S0, S2 non-authenticated),- Magenta - successful (Security S2 Authenticated),- Rednot successful.To add the device to the Z-Wave network using SmartStart:1.Set the main controller in Security S2 Authenticated add mode (see the controllers manual). 2.Scan the DSK QR code or input the underlined part of the DSK (label on the bottom of the box).3.Power the device.4.Wait for the adding process to start (up to few minutes), which is signaled with yellow LED blinking.5.Adding result will be confirmed by the Z-Wave controllers message and the LED frame:- Green - successful (non-secure, S0, S2 non-authenticated),- Magenta - successful (Security S2 Authenticated),- Rednot successful.

Exclusion

To remove the device from the Z-Wave network:1.Power the device.2.Set the main controller into remove mode (see the controllers manual).3.Quickly, three times click one of the buttons.4.LED will start blinking yellow, wait for the removing process to end.5.Successful removing will be confirmed by the Z-Wave controllers message and red LED colour.

Communication to a Sleeping device (Wakeup)

This device is battery operated and turned into deep sleep state most of the time to save battery life time. Communication with the device is limited. In order to communicate with the device, a static controller C is needed in the network. This controller will maintain a mailbox for the battery operated devices and store commands that can not be received during deep sleep state. Without such a controller, communication may become impossible and/or the battery life time is significantly decreased.

This device will wakeup regularly and announce the wakeup state by sending out a so called Wakeup Notification. The controller can then empty the mailbox. Therefore, the device needs to be configured with the desired wakeup interval and the node ID of the controller. If the device was included by a static controller this controller will usually perform all necessary configurations. The wakeup interval is a tradeoff between maximal battery life time and the desired responses of the device. To wakeup the device please perform the following action: FIBARO Walli Roller Shutter is powered using DC power supply unit so it is always awake.

Quick trouble shooting

Here are a few hints for network installation if things dont work as expected.

  1. Make sure a device is in factory reset state before including. In doubt exclude before include.
  2. If inclusion still fails, check if both devices use the same frequency.
  3. Remove all dead devices from associations. Otherwise you will see severe delays.
  4. Never use sleeping battery devices without a central controller.
  5. Dont poll FLIRS devices.
  6. Make sure to have enough mains powered device to benefit from the meshing

Association - one device controls an other device

Z-Wave devices control other Z-Wave devices. The relationship between one device controlling another device is called association. In order to control a different device, the controlling device needs to maintain a list of devices that will receive controlling commands. These lists are called association groups and they are always related to certain events (e.g. button pressed, sensor triggers, ...). In case the event happens all devices stored in the respective association group will receive the same wireless command wireless command, typically a 'Basic Set' Command.

Association Groups:

Group Number Maximum Nodes Description
1 1 1st association groupLifeline reports the device status and allowsfor assigning single device only (main controller by default).
2 5 2nd association groupRoller Shutter is assigned to shutter position controlUP/DOWN (uses Switch Multilevel command class).
3 5 3rd association groupSlats is assigned to slats position controlUP/DOWN (uses Switch Multilevel command class). The device allows to control 5 regular or multichannel

Configuration Parameters

Z-Wave products are supposed to work out of the box after inclusion, however certain configuration can adapt the function better to user needs or unlock further enhanced features.

IMPORTANT: Controllers may only allow configuring signed values. In order to set values in the range 128 ... 255 the value sent in the application shall be the desired value minus 256. For example: To set a parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56. In case of a two byte value the same logic applies: Values greater than 32768 may needed to be given as negative values too.

Parameter 11: LED framecolour when moving

This parameter defines the LED colour when the motor is running.
Size: 1 Byte, Default Value: 1

Setting Description
0 LED disabled
1 White
2 Red
3 Green
4 Blue
5 Yellow
6 Cyan
7 Magenta
8 colour changes smoothly depending on measured power
9 colour changes in steps depending on measured power

Parameter 12: LED framecolour when not moving


Size: 1 Byte, Default Value: 0

Setting Description
0 LED disabled
1 White
2 Red
3 Green
4 Blue
5 Yellow
6 Cyan
7 Magenta

Parameter 13: LED framebrightness

This parameter allows to adjust the LED frame brightness.
Size: 1 Byte, Default Value: 100

Setting Description
0 LED disabled
1 - 100 (1-100% brightness)

Parameter 150: Force calibration

By setting this parameter to 2 the device enters the calibration mode. The parameter relevant only if the device is set to work in positioning mode (parameter 151 set to 1 or 2).
Size: 1 Byte, Default Value: 0

Setting Description
0 device is not calibratedv
1 device is calibrated
2 force device calibration

Parameter 151: Operating mode

This parameter allows adjusting operation according to the connected device.
Size: 1 Byte, Default Value: 1

Setting Description
1 roller blind (with positioning)
2 Venetian blind (with positioning)
5 roller blind with built-in driver
6 roller blind with built-in driver (impulse)

Parameter 152: Venetian blindtime of full turn of the slats

For Venetian blinds (parameter 151 set to 2) the parameter determines time of full turn cycle of the slats.The parameter is irrelevant for other modes.
Size: 4 Byte, Default Value: 0

Setting Description
0 - 65535 (0 - 655.35s, every 0.01s) - time of turn

Parameter 153: Set slats back to previous position

For Venetian blinds (parameter 151 set to 2) the parameter determines slats positioning in various situations. The parameter is irrelevant for other modes.
Size: 1 Byte, Default Value: 1

Setting Description
0 slats return to previously set position only in case of the main controller operation
1 slats return to previously set position in case of the main controller operation, momentary switch operation, or when the limit switch is reached
2 slats return to previously set position in case of the main controller operation, momentary switch operation, when the limit switch is reached or after receiving the Switch Multilevel Stop control frame

Parameter 154: Delay motor stop after reaching end switch

The parameter determines the time after which the motor will be stopped after end switch contacts are closed.
Size: 2 Byte, Default Value: 10

Setting Description
1 - 255 (0.1s - 25.5 seconds)

Parameter 155: Motor operation detection

Power threshold interpreted as reaching a limit switch.
Size: 2 Byte, Default Value: 10

Setting Description
0 no detection
1 - 255 (1-255W) - report interval

Parameter 156: Time of up movement

This parameter determines the time needed for roller blinds to reach the top.For modes with positioning value is set automatically during calibration, otherwise, it must be set manually.
Size: 4 Byte, Default Value: 6000

Setting Description
1 - 65535 (0.01 - 655.35 seconds)

Parameter 157: Time of down movement

This parameter determines the time needed forroller blinds to reach the bottom.For modes with positioning value is set automatically during calibration, otherwise, it must be set manually.
Size: 4 Byte, Default Value: 6000

Setting Description
1 - 65535 (0.01 - 655.35 seconds)

Parameter 24: Buttons orientation

This parameter allows reversing the operation of the buttons.
Size: 1 Byte, Default Value: 0

Setting Description
0 default (1st button UP, 2nd button DOWN)
1 reversed (1st button DOWN, 2nd button UP)

Parameter 25: Outputs orientation

This parameter allows reversing the operation of Q1 and Q2 without changing the wiring (e.g. in case of invalid motor connection).
Size: 1 Byte, Default Value: 0

Setting Description
0 (Q1UP, Q2DOWN)LED disabled
1 reversed (Q1DOWN, Q2UP)

Parameter 30: Alarm configuration - 1st slot

This parameter determines to which alarm frames and how the device should react. The parameters consist of 4 bytes, three most significant bytes are set according to the official Z-Wave protocol specification.
Size: 4 Byte, Default Value: 0

Setting Description
1 - 0 [MSB]Notification Type
2 Notification Value
3 Event/State Parameters
4 [LSB]action

Parameter 31: Alarm configuration - 2nd slot

This parameter determines to which alarm frames and how the device should react. The parameters consist of 4 bytes, three most significant bytes are set according to the official Z-Wave protocol specification.
Size: 4 Byte, Default Value: 0

Setting Description
1 [MSB]Notification Type
2 Notification Value
3 Event/State Parameters
4 [LSB]action

Parameter 32: Alarm configuration - 3rd slot

This parameter determines to which alarm frames and how the device should react. The parameters consist of 4 bytes, three most significant bytes are set according to the official Z-Wave protocol specification.
Size: 4 Byte, Default Value: 0

Setting Description
1 [MSB]Notification Type
2 Notification Value
3 Event/State Parameters
4 [LSB]action

Parameter 33: Alarm configuration - 4th slot

This parameter determines to which alarm frames and how the device should react. The parameters consist of 4 bytes, three most significant bytes are set according to the official Z-Wave protocol specification.
Size: 4 Byte, Default Value: 0

Setting Description
0 Notification Type
1 [MSB]Notification Type
2 Notification Status
3 Event/State Parameters
4 [LSB]action

Parameter 34: Alarm configuration - 5th slot

This parameter determines to which alarm frames and how the device should react. Theparameters consist of 4 bytes, three most significant bytes are set according to the officialZ-Wave protocol specification.
Size: 4 Byte, Default Value: 0

Setting Description
1 [MSB]Notification Type
2 Notification Status
3 Event/State Parameters
4 [LSB] - action

Parameter 35: Alarm configurationduration

This parameter defines duration of alarm sequence.When time set in this parameter elapses, alarm is cancelled, LED frame and relay restore normal operation, but do not recover state from before the alarm.
Size: 2 Byte, Default Value: 600

Setting Description
0 infinite
1 - 32400 (1s-9h, 1s step)duration

Parameter 40: First buttonscenes sent

This parameter determines which actions result in sending scene IDs assigned to them. Values can be combined (e.g. 1+2=3 means that scenes for single and double click are sent). Enabling scenes for triple click disables entering the device in learn mode by triple clicking.
Size: 1 Byte, Default Value: 0

Setting Description
1 Key pressed 1 time
2 Key pressed 2 time
4 Key pressed 3 time
8 Key hold down and key released

Parameter 41: Second buttonscenes sent

This parameter determines which actions result in sending scene IDs assigned to them. Values can be combined (e.g. 1+2=3 means that scenes for single and double click are sent). Enabling scenes for triple click disables entering the device in learn mode by triple clicking.
Size: 1 Byte, Default Value: 0

Setting Description
1 Key pressed 1 time
2 Key pressed 2 time
4 Key pressed 3 time
8 Key hold down and key released

Parameter 60: Power reportsinclude self-consumption

This parameter determines whether the power measurements should include power consumed by the device itself.
Size: 1 Byte, Default Value: 0

Setting Description
0 Self-consumption not included
1 Self-consumption included

Parameter 61: Power reportson change

This parameter defines minimal change (from the last reported) in measured power that results in sending new report. For loads under 50W the parameter is irrelevant, report are sent every 5W change.
Size: 2 Byte, Default Value: 15

Setting Description
0 reporting on change disabled
1 - 500 (1-500%, 1% step)minimal change

Parameter 62: Power reportsperiodic

This parameter defines reporting interval for measured power. Periodic reports are independent from changes in value (parameter 61).
Size: 2 Byte, Default Value: 3600

Setting Description
0 periodic reports disabled
30 - 32400 (30s-9h, 1s step)time interval

Parameter 65: Energy reportson change

This parameter defines minimal change (from the last reported) in measured energy that results in sending new report.
Size: 2 Byte, Default Value: 10

Setting Description
0 reporting on change disabled
1 - 500 (0.01-5kWh, 0.01kWh step)minimal change

Parameter 66: Energy reportsperiodic

This parameter defines reporting interval for measured energy.Periodic reports are independent from changes in value (parameter 66).
Size: 2 Byte, Default Value: 3600

Setting Description
0 periodic reports disabled
30 - 32400 (30s-9h, 1s step)time interval

Technical Data

Hardware Platform ZM5101
Device Type Window Covering - Endpoint Aware
Network Operation Always On Slave
Firmware Version HW: 1 FW: 5.00:05.00
Z-Wave Version 6.81.01
Certification ID ZC10-19046411
Z-Wave Product Id 0x010F.0x1D01.0x1000
Switch Type Push Button
Loads Controlled 2
Supported Meter Type Electric Energy
Supported Notification Types Power ManagementSystem
Electric Load Type Inductive (e.g. Motor)
Color White
Security V2 S2_AUTHENTICATED
Frequency XXfrequency
Maximum transmission power XXantenna

Supported Command Classes

  • Application Status
  • Association Grp Info V2
  • Association V2
  • Basic
  • Central Scene V3
  • Configuration
  • Crc 16 Encap
  • Device Reset Locally
  • Firmware Update Md V4
  • Manufacturer Specific V2
  • Meter V3
  • Multi Channel Association V3
  • Multi Channel V4
  • Notification V8
  • Powerlevel
  • Protection V2
  • Security
  • Security 2
  • Supervision
  • Switch Multilevel V4
  • Transport Service V2
  • Version V2
  • Zwaveplus Info V2
    •

Controlled Command Classes

  • Switch Multilevel V4
    •

Explanation of Z-Wave specific terms

  • Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways,Remote Controls or battery operated wall controllers.
  • Slave — is a Z-Wave device without capabilities to manage the network. Slaves can be sensors, actuators and even remote controls.
  • Primary Controller — is the central organizer of the network. It must be a controller. There can be only one primary controller in a Z-Wave network.
  • Inclusion — is the process of adding new Z-Wave devices into a network.
  • Exclusion — is the process of removing Z-Wave devices from the network.
  • Association — is a control relationship between a controlling device and a controlled device.
  • Wakeup Notification — is a special wireless message issued by a Z-Wave device to announces that is able to communicate.
  • Node Information Frame — is a special wireless message issued by a Z-Wave device to announce its capabilities and functions.
